| Tempat asal: | Cina |
|---|---|
| Nama merek: | VEGASHINE / OEM |
| Nomor model: | BF10212001-H170 |
| Kuantitas min Order: | 1 unit |
| Kemasan rincian: | Karton |
| Waktu pengiriman: | 3 sampai 10 hari kerja |
| Syarat-syarat pembayaran: | T/T, Western Union, MoneyGram |
| Menyediakan kemampuan: | 1000 unit per bulan |
| Casis: | sasis lembaran baja galvanis | Dimensi: | 440mm * 250mm * 44mm |
|---|---|---|---|
| Warna sasis: | hitam | CPU: | Intel® 6/7/8/9 Core® i3/i5/i7 |
| Penyimpanan: | 2 * DDR4 | Gigabit LAN: | 12* RJ45 Gigabit Ethernet Port |
| Pelabuhan COM: | 1 * port serial standar CISCO |
Melihat :
Model No.BF10212001-H170 mendukung prosesor Intel® 6/7/8/9th Core® i3/i5/i7.
Saat Anda bertanya, Anda dapat memilih CPU berikut
Prosesor Intel® Xeon® Skylake E3-1225 v5 4 core 4 thread 3.3~3.7Ghz prosesor
Prosesor Intel® Intel® Core™ Skylake i3-6100 2 core 4 thread prosesor 3,7Ghz
Prosesor Intel® Intel® Core™ Skylake i5-6400 4 core 4 thread 2,7~3,3Ghz prosesor
Prosesor Intel® Intel® Core™ Skylake i7-6700 4 core 8 thread 3.4~4.0Ghz prosesor
Prosesor Intel® Celeron® Coffee Lake G4900 2 core 2 thread prosesor 3,1Ghz
Prosesor Intel® Pentium® Gold Coffee Lake G5400 2 core 4 thread prosesor 3,7Ghz
Prosesor Intel® Core™ i3-9100 Coffee Lake quad core 4 thread 3.6~4.2Ghz
Prosesor Intel® Core™ i5-9400 Coffee Lake 6 core 6 thread 2.9~4.1Ghz
Prosesor Intel® Core™ i7-9700 Coffee Lake 8 core 8 thread 3.0~4.7Ghz
1U chassis12 Gigabit LAN H170 firewall alat PC router lembut mendukung 6/7/8/9thI3 I5 I7 Komputer industri mendukung pFsense Mikrotik
Fitur Utama
Mendukung prosesor LGA1151 Intel® 6/7/8/9th Core® i3/i5/i7
Mengadopsi chipset kecepatan tinggi Intel® H170
Mendukung 2 * slot memori DDR4 maks hingga 64GB
Intel® HD Graphics terintegrasi
1 *HDMI
Mendukung tempat HDD 1*2.5" / 1*3.5'
Mendukung ekspansi 1 * MSATA SSD
12* Gigabit LAN
1 * port serial standar CISCO
2 * USB3.0
Catu daya AC 110V ~ 240V ATX
Dimensi: 440mm * 250mm * 44mm
Sasis lembaran baja galvanis berkualitas tinggi
Metode pemasangan rak standar 1U
Spesifikasi
| Model nomor. | BF10212001-H170 | |
| Casis | Warna | Hitam |
| Dimensi | 440mm * 250mm * 44mm | |
| Struktur | Sasis standar 1U | |
| Bahan | Lembaran baja galvanis berkualitas tinggi | |
| Instalasi | Metode pemasangan rak standar 1U | |
| Platform | Prosesor | Mendukung LGA1151 Gen 6/7/8/9thProsesor Intel® Core® i3/i5/i7 |
| Chipset | Mengadopsi chipset kecepatan tinggi Intel® H170 | |
| Grafik |
Intel® HD Graphics terintegrasi mendukung 1 * output tampilan HDMI |
|
| Penyimpanan | Penyimpanan | 2 * slot memori DDR4, mendukung 2133/2400/2666MHz, maksimal hingga 64GB |
| HDD | Mendukung ruang HDD 1*2.5" / 1*3.5' (antarmuka 3 * SATA3.0) | |
| SSD | Mendukung ekspansi 1 * MSATA SSD | |
| Audio | Audio | T/A |
| Jaringan | Ethernet |
8* Intel i211, 1000/100/10Mbps 4*Intel 82580 Gigabit LAN |
| Wi-Fi /4G | 1 * Mini PCIe mendukung modul WIFI / 4G (Untuk opsional) | |
| I/O depan | Port Serial | 1 * konsol port serial standar CISCO |
| USB | 2 * USB3.0 | |
| LAN | 8 * Port Ethernet Gigabit RJ45 | |
| DIPIMPIN | 1 * LED HDD, 1 * LED Daya | |
| Kembali I/O | Menampilkan | 1 *HDMI |
| Saklar daya | 1 * Sakelar daya | |
| Sumber Daya listrik | 1 * Antarmuka Daya ATX | |
| Sumber Daya listrik | Memasukkan | AC 110V ~ 240V |
| Jenis | Catu daya ATX | |
| Keandalan | Suhu Operasi | 0℃~45℃ |
| Suhu Penyimpanan | -20 ℃ ~ 70 ℃ | |
| Kelembaban relatif | 5%-95%, tanpa kondensasi | |
| Getaran | 0,5g rms/5-500HZ/acak/operasi | |
| Mengoperasikan Sistem | Mendukung Win 7/8/10, Linux, Pfsense, Mikrotik, iKuai, WayOS, LEDE, Openwrt, Panabit, Smart6 , Ubuntu , Centos dll. | |
